Casavant Frères Ltée.
Opus 3629, 1987

Sanctuary; front

33 Allen Street East
Waterloo, ON, CA

24 Ranks - 1,320 Pipes

EXPLORE IMAGES VIEW STOPLIST

ADDITIONAL INFORMATION

Something not quite correct?Suggest an Edit

IMAGES

Category:

Only show images in a specific category ☝️

Something missing or not quite correct?Add ImageorSuggest an Edit

STOPLISTS

Selected Item:

View additional stoplist entries if they exist ☝️

Click on a stop or division name for additional details if marked with .

	Swell (II - Expressive) Position: In Side Chambers at the Front of the Room. Facade Pipes or Case Front Visible Chest Action: Electro Pneumatic (Pitman) Stop Action: Pneumatic (Electro Pneumatic)
8'	Chimney Flute	56
8'	Gamba	56
8'	Voix Celeste [tc] Notes: TC	44
4'	Gemshorn	56
2'	Principal	56
III	Cymbel	168
16'	Dulzian	56
8'	Trompette	56

	Great (I) Position: In Side Chambers at the Front of the Room. Facade Pipes or Case Front Visible Chest Action: Electro Pneumatic (Pitman) Stop Action: Pneumatic (Electro Pneumatic)
8 '	Open Diapason	56
8'	Spitz Flote	56
8'	Gedeckt	56
4'	Octave	56
4'	Koppel Flote	56
2'	Open Flute	56
II	Cornet	112
IV	Fourniture	224

8'	Swell to Great

	Pedal Position: In Side Chambers at the Front of the Room. Facade Pipes or Case Front Visible Chest Action: Electro Pneumatic (Unit) Stop Action: Pneumatic (Electro Pneumatic)
16'	Bourdon	32
8'	Principal	32
8'	Bourdon Notes: ext. Bourdon 16'	12
4'	Octave Notes: ext. Pedal Principal 8'	12
16'	Bombarde Notes: ext. Sw. 8' Trompette. On unit chest in swellbox	12 SW

8'	Swell to Pedal
8'	Great to Pedal

Open In New Tab

Something missing or not quite correct?Add StoplistorSuggest an Edit

CONSOLES

Selected Item:

View additional console entries if they exist ☝️

Builder: Casavant Frères Ltée.

Position: Unknown

Design: Traditional With Roll Top

Pedalboard Type: Concave Radiating (Meeting AGO Standards)

Features:

2 Manuals (61 Notes)32 Note Pedal3 Divisions18 StopsElectrical Key ActionElectrical Stop ActionCrescendoCombination Thumb Piston(s)Combination Toe Piston(s)Coupler Thumb Piston(s)Coupler Toe Piston(s)Sforzando Thumb Piston(s)Sforzando Toe Piston(s)

Stop Layout: Tilting/Rocking Tablets Above Top Manual

Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)

Combination Action: Adjustable Combination Pistons

Control System: Unknown or N/A

Something missing or not quite correct?Add ConsoleorSuggest an Edit

DETAILS

Switch between notes, documents, audio, and blowers ☝️

This instrument is: Extant and Playable in this location

Database Manager on April 16th, 2019:

Updated by René Le Grand: The opus number is 3629 from my files.

Database Manager on February 17th, 2019:

Updated by René Le Grand, listing this web site as a source of information: http://holy-saviour.on.ca/. Case in right side chamber at the front of the church with visible pipes.

Database Manager on July 19th, 2015:

Updated through information in Casavant documents, courtesy of Simon Couture and Denis Blaine. The tonal director was Jean-Louis Coignet.

Database Manager on October 6th, 2009:

Identified by Rae Bolton from information furnished by Casavant Freres, courtesy of Simon Couture.

Something missing or not quite correct?Add NoteorAdd WebpageorAdd Cross ReferenceorSuggest an Edit

Pipe Organ Database

A project of the Organ Historical Society

Website by John Roper Account Login

Casavant Frères Ltée.Opus 3629, 1987

Church of the Holy Saviour
