Randall Karstens (R Karstens Organ Works, Ltd)
2023
Originally Clarence Helsing (1963)
Swedesburg Lutheran Church
1897 140th Street
Mt. Pleasant, IA, US
28 Ranks - 1,911 Pipes
Instrument ID: 70132 ● Builder ID: 8329 ● Location ID: 56204
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLISTSomething not quite correct?Suggest an Edit
Plenum Organ Company
🤝 Instrument entries in Illinois sponsored by:
We are grateful for the generous support of our sponsors, who make it possible for us to continue our mission of preserving and promoting the rich history of pipe organs across the globe.
IMAGES
Category:
Only show images in a specific category ☝️
Something missing or not quite correct?Add ImageorSuggest an Edit
STOPLISTS
Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
| Great (2nd Keyboard)🛈 | ||
| 16' | Violoncello🛈 | |
| 8' | Open Diapason🛈 | |
| 8' | Viola Pomposa🛈 | |
| 8' | Harmonic Flute🛈 | |
| 8' | Stopped Diapason🛈 | |
| 4' | Octave🛈 | |
| 4' | Octave Flute🛈 | |
| 4' | Bourdon🛈 | |
| 2' | Fifteenth🛈 | |
| III-IV | Mixture🛈 | |
| 8' | Tromba🛈 |
| Swell (3rd Keyboard)🛈 | ||
| 16' | Lieblich Gedeckt🛈 | |
| 8' | Violin Diapason🛈 | |
| 8' | Salicional🛈 | |
| 8' | Voix Celeste🛈 | |
| 8' | Gedeckt🛈 | |
| 4' | Violin Octave🛈 | |
| 4' | Flute d’amour🛈 | |
| 2' | Piccolo🛈 | |
| III | Mixture🛈 | |
| 16' | Contra Fagotto🛈 | |
| 8' | Trumpet🛈 | |
| 8' | Oboe🛈 | |
| 4' | Clarion🛈 |
| Choir (1st Keyboard)🛈 | ||
| 8' | Viola Pomposa🛈 | |
| 8' | Dulciana🛈 | |
| 8' | Unda Maris🛈 | |
| 8' | Melodia🛈 | |
| 8' | Chimney Flute🛈 | |
| 4' | Octave Viol🛈 | |
| 4' | Open Flute🛈 | |
| 4' | Chimney Flute🛈 | |
| 2⅔' | Nazard🛈 | |
| 2' | Flautino🛈 | |
| 1⅗' | Tierce🛈 | |
| 8' | Clarinet🛈 |
| Solo (Floating)🛈 | ||
| 8' | Major Diapason🛈 | |
| 8' | Major Flute🛈 | |
| 8' | Choeur des Viols🛈 | |
| 4' | Major Octave🛈 | |
| 4' | Major Flute🛈 | |
| 16' | Trombone🛈 | |
| 8' | Tromba🛈 | |
| 4' | Clarion🛈 | |
| Chimes🛈 |
| Pedal🛈 | ||
| 32' | Resultant🛈 | |
| 16' | Open Wood🛈 | |
| 16' | Violoncello🛈 | |
| 16' | Major Bass🛈 | |
| 16' | Lieblich Gedeckt🛈 | |
| 8' | Octave🛈 | |
| 8' | Viola Pomposa🛈 | |
| 8' | Major Flute🛈 | |
| 8' | Gedeckt🛈 | |
| 4' | Fifteenth🛈 | |
| 4' | Octave Viol🛈 | |
| 4' | Major Flute🛈 | |
| 16' | Trombone🛈 | |
| 16' | Contra Fagotto🛈 | |
| 8' | Tromba🛈 | |
| 8' | Trumpet🛈 | |
| 4' | Tromba Clarion🛈 | |
| 4' | Clarinet🛈 |
Something missing or not quite correct?Add StoplistorSuggest an Edit
CONSOLES
Selected Item:
View additional console entries if they exist ☝️
Builder: Randall Karstens (R Karstens Organ Works, Ltd)
Position: Console in Fixed Position, Right
Design: Traditional With Roll Top
Pedalboard Type: Concave Radiating (Meeting AGO Standards)
Features:
3 Manuals (61 Notes)32 Note Pedal5 Divisions62 Stops90 RegistersElectrical Key ActionElectrical Stop Action✓ Crescendo✓ Combination Thumb Piston(s)✓ Combination Toe Piston(s)✓ Coupler Thumb Piston(s)✓ Sforzando Thumb Piston(s)Stop Layout: Tilting/Rocking Tablets Above Top Manual
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination Action: Computerized/Digital
Control System: Unknown or N/A
Something missing or not quite correct?Add ConsoleorSuggest an Edit
DETAILS
Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location
Related Instrument Entries: Bennett Organ Co. (1928) , Clarence Helsing (1963)
