J. Allen Farmer, Inc.
2006 - 2008

Originally Geo. Stevens (& Co.) (1866)

Trinity Episcopal Church

Sanctuary

182 NC Hwy 33 West
Chocowinity, NC, US

12 Ranks - 581 Pipes - 3 Physical Divisions
EXPLORE IMAGESVIEW STOPLIST
ADDITIONAL INFORMATION

Something not quite correct?Suggest an Edit

IMAGES

Category:
Only show images in a specific category ☝️

Something missing or not quite correct?Add ImageorSuggest an Edit

STOPLISTS

Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
  • Position: In a Case in a Side Transept
  • Chest Action: Slider With Mechanical Pull-Downs
  • Stop Action: Mechanical (Slider)
  • Notes: open, metal, includes façade pipes
  • 8' Swell to Great
8'58
8'58
4'58
2 2⁄3'58
2'58
1 3⁄5'58
  • Position: In a Case in a Side Transept
  • Chest Action: Slider With Mechanical Pull-Downs
  • Stop Action: Mechanical (Slider)
  • Notes: wood
8'46
8'58
8'46
4'58
8'46
  • Position: In a Case in a Side Transept
  • Chest Action: Other
  • Stop Action: Mechanical (Details Unknown)
  • 8' Great to Pedal
  • 8' Swell to Pedal
16'25

Tremolo (affects all divisions) Bell (prepared stop)

Open In New Tab

Something missing or not quite correct?Add StoplistorSuggest an Edit

CONSOLES

Selected Item:
View additional console entries if they exist ☝️
Builder: Geo. Stevens (& Co.)
Position: Keydesk Attached
Design: Traditional With a Keyboard Cover That Can Be Lifted To Form a Music Rack
Pedalboard Type: Flat Straight
Features:
2 Manuals (58 Notes)27 Note Pedal3 Divisions12 StopsMechanical (Unknown) Key ActionMechanical Stop Action
Stop Layout: Drawknobs in Horizontal Rows on Terraced/Stepped Jambs
Expression Type: Balanced Expression Shoes/Pedals (Details Unknown)
Combination Action: None
Control System: Unknown or N/A

Something missing or not quite correct?Add ConsoleorSuggest an Edit

DETAILS

Switch between notes, documents, audio, and blowers ☝️
This instrument is: Extant and Playable in this location

Jim Stettner on February 26th, 2024:

Updated through email from Shirley Kuhn, Music Dir.: In the mid-1980’s, J. Allen Farmer, Inc., of Winston-Salem, NC re-leathered the bellows and refinished the case work and the façade pipes. In 2006 John moved the organ to his shop in Winston-Salem for a major refurbishment, including new chests and wind system, a rebuild of the pedalboard, and several additions. The instrument returned in 2008 for a re-dedication on September 21. The organ now has 13 stops/12 ranks and 607 pipes. In 2019, a Zimbelstern was added.

Jim Stettner on February 26th, 2024:

This entry represents the rebuilding with tonal modifications of an existing organ.

Related Instrument Entries: Unknown Builder (1944) , Geo. Stevens (& Co.) (1866) , Unknown Builder (1914)

Something missing or not quite correct?Add NoteorAdd WebpageorAdd Cross ReferenceorSuggest an Edit
