| Great (I)🛈 | ||
| 16' | Bourdon | 58 |
| 8' | Principal | 58 |
| 8' | Hohlflöte | 58 |
| 8' | Salicional | 58 |
| 4' | Octave | 58 |
| 4' | Harmonic Flute | 58 |
| 2 2⁄3' | Quinte | 58 |
| 2' | Superoctave | 58 |
| IV | Cornet | 232 |
| IV-V | Mixture | 278 |
| 8' | Trompet | 58 |
| 8' | Swell to Great |
| Swell (II - Expressive)🛈 | ||
| 8' | Gedackt | 58 |
| 8' | Viol da Gambe | 58 |
| 8' | Gambe Celeste | 58 |
| 4' | Principal | 58 |
| 4' | Rohrflöte | 58 |
| 2 2⁄3' | Nasat | 58 |
| 2' | Gemshorn | 58 |
| II | Sesquialtera | 116 |
| III | Mixture | 174 |
| 16' | Bassoon | 58 |
| 8' | Oboe | 58 |
| Pedal🛈 | ||
| 16' | Subbass | 30 |
| 16' | Bourdon | GT |
| 8' | Octave | 30 |
| 8' | Gedackt | SW |
| 4' | Octave | 30 |
| 16' | Posaune | 30 |
| 16' | Bassoon | SW |
| 8' | Trompet | GT |
| 8' | Great to Pedal | |
| 8' | Swell to Pedal |
Tremulant Zimbelstern Nachtigall Metal pipes of hammered lead-tin alloys Natural keys of polished cow bone Sharps and stop knobs of ebony Cases of solid white oak Mechanical key action, electric stop and combination action with sequencer Manual compass: C-a''', 58 notes Pedal compass: C-f', 30 notes Temperament: Kellner Pitch: a' = 440 Stops: 30 Wind Stabilizer 3 wedge bellows with pumping levers Detached console pipe counts calculated
