Robert G. Dial - Organ Builders
St Francis Borgia Catholic Parish (1869)
115 Cedar Street
Washington, MO, US
27 Ranks - 1,613 Pipes - 3 Physical Divisions
Instrument ID: 72937 ● Builder ID: 7946 ● Location ID: 57685
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLISTSomething not quite correct?Suggest an Edit
IMAGES
Category:
Only show images in a specific category ☝️
Something missing or not quite correct?Add ImageorSuggest an Edit
STOPLISTS
Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
| Great (I)🛈 | ||
| 16' | Double Open Diapason | |
| 8' | Open Diapason | 85 |
| 8' | Doppelflote | 61 |
| 8' | Stopped Diapason | 61 |
| 8' | Melodia | 61 |
| 8' | Viole de Gamba | 61 |
| 8' | Dulciana | 61 |
| 4' | Octave | GT 8' Diapason |
| 4' | Principal | 61 |
| 4' | Flute d'Amour | 61 |
| 2 2⁄3' | Twelfth | 61 |
| 2' | Super Octave | 61 |
| III | Mixture | 183 |
| 8' | Trumpet | 61 |
| 16' | Great to Great | |
| Great Unison Off | ||
| 4' | Great to Great | |
| 16' | Swell to Great | |
| 8' | Swell to Great | |
| 4' | Swell to Great |
| Swell (II - Expressive)🛈 | ||
| 16' | Bourdon | 61 |
| 8' | Geigen Diapason | 61 |
| 8' | Lieblich Gedeckt | 61 |
| 8' | Salicional | 61 |
| 8' | Voix Celeste | 49 TC |
| 8' | Aeoline | 61 |
| 4' | Flute Amabile | 61 |
| 4' | Violina | 61 |
| 2' | Piccolo | 61 |
| 8' | Cornopean | 61 |
| 8' | Oboe | 61 |
| Tremulant | ||
| 16' | Swell to Swell | |
| Swell Unison Off | ||
| 4' | Swell to Swell |
| Pedal🛈 | ||
| 32' | Resultant🛈 | |
| 16' | Open Diapason🛈 | GT 8' |
| 16' | Subbass | 44 |
| 16' | Lieblich Gedeckt | SW 16' |
| 8' | Diapason | GT |
| 8' | Bassflute | PD 16' |
| 8' | Violoncello | 32 |
| 4' | Octave | GT 8' Diapason |
| 4' | Flute🛈 | PD 16' Subbass |
| 32' | Contre Bombarde | PF |
| 16' | Bombarde | PF |
| 8' | Trompette | GT |
| 8' | Great to Pedal | |
| 4' | Great to Pedal | |
| 8' | Swell to Pedal | |
| 4' | Swell to Pedal |
Something missing or not quite correct?Add StoplistorSuggest an Edit
CONSOLES
Selected Item:
View additional console entries if they exist ☝️
Builder: Organ Supply Industries (OSI)
Position: Movable Console
Design: Traditional With Roll Top
Pedalboard Type: Concave Radiating (Meeting AGO Standards)
Features:
2 Manuals (61 Notes)32 Note Pedal3 Divisions27 Stops37 RegistersElectrical Key ActionElectrical Stop Action✓ Crescendo✓ Transposer✓ MIDI✓ Combination Thumb Piston(s)✓ Combination Toe Piston(s)✓ Coupler Thumb Piston(s)✓ Coupler Toe Piston(s)✓ Sforzando Thumb Piston(s)✓ Sforzando Toe Piston(s)Stop Layout: Tilting/Rocking Tablets Above Top Manual
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination Action: Computerized/Digital
Control System: Peterson
Something missing or not quite correct?Add ConsoleorSuggest an Edit
DETAILS
Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location
Joseph Eckelkamp on April 11th, 2025:
This is the third rebuild of the organ, with earlier work converting the Schuelke from tubular pneumatic to Kilgen's electro-pneumatic ventil and unit actions. Robert Dial's work included replacing the Great and Swell reeds, new electronics, and a new console.
This is the third rebuild of the organ, with earlier work converting the Schuelke from tubular pneumatic to Kilgen's electro-pneumatic ventil and unit actions. Robert Dial's work included replacing the Great and Swell reeds, new electronics, and a new console.
Related Instrument Entries: Wm. Schuelke Organ Co. (1909)
