Balcom and Vaughan Pipe Organs, Inc.
2017
Originally Balcom and Vaughan Pipe Organs, Inc. (Opus 792, 1972)
All Saints Episcopal Church
1322 Kimball Avenue
Richland, WA, US
13 Ranks - 896 Pipes
Instrument ID: 24813 ● Builder ID: 7403 ● Location ID: 21967
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLISTSomething not quite correct?Suggest an Edit
IMAGES
Category:
Only show images in a specific category ☝️
Something missing or not quite correct?Add ImageorSuggest an Edit
STOPLISTS
Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
| Great (I)🛈 | ||
| 8' | Principal🛈 | 61 |
| 8' | Rohr Flöte | 61 |
| 8' | Spitz Gamba | SW |
| 4' | Octave | 61 |
| 4' | Rohr Flöte | 12 ext. 8' R.F. |
| 2' | Octave [1992] | 12 ext. 4' Oct. |
| 1⅓' | Quint Flöte | 7 ext. Sw 2⅔' Nas. |
| III | Mixture 19-22-26 | 183 |
| 8' | Hautbois | SW |
| Zimbelstern [1992] | ||
| 4' | Great to Great | |
| 16' | Swell to Great | |
| 8' | Swell to Great | |
| 4' | Swell to Great |
| Swell (II - Expressive)🛈 | ||
| 8' | Gedackt | 61 |
| 8' | Spitz Gamba | 61 |
| 4' | Italian Principal | 61 |
| 4' | Spill Flöte [1992] | 61 |
| 2⅔' | Nasat [1992] | 61 |
| 2' | Spill Flöte [1992] | 12 ext. 4' S.F. |
| 1⅗' | Terz [1992] | 61 |
| 1' | Sifflöte🛈 | 36 ext. 8' Ged. |
| 8' | Hautbois | 61 |
| Tremulant | ||
| 16' | Swell to Swell | |
| Swell Unison Off | ||
| 4' | Swell to Swell |
| Pedal🛈 | ||
| 16' | Gedackt Bass | 12 ext. Sw 8' Ged. |
| 8' | Principal | GT |
| 8' | Spiz Gamba | SW |
| 8' | Gedackt | SW |
| 4' | Choral Bass | from GT 8' |
| 4' | Rohr Flöte | GT |
| 2' | Octavin | from GT 8' |
| III | Mixture 22-26-29🛈 | from GT 4' Oct. |
| 16' | Basson | 12 ext. Sw 8' Haut. |
| 8' | Hautbois | SW |
| 4' | Hautbois | SW |
| blank | ||
| 8' | Swell to Pedal | |
| 4' | Swell to Pedal | |
| 8' | Great to Pedal |
Something missing or not quite correct?Add StoplistorSuggest an Edit
CONSOLES
Selected Item:
View additional console entries if they exist ☝️
Builder: Balcom and Vaughan Pipe Organs, Inc.
Position: Console in Fixed Position, Right
Design: Traditional With Roll Top
Pedalboard Type: Concave Radiating (Meeting AGO Standards)
Features:
2 Manuals (61 Notes)32 Note Pedal2 Divisions11 Stops30 RegistersElectrical Key ActionElectrical Stop Action✓ Crescendo✓ Sequencer✓ Combination Thumb Piston(s)✓ Combination Toe Piston(s)✓ Coupler Thumb Piston(s)✓ Coupler Toe Piston(s)✓ Sforzando Thumb Piston(s)✓ Sforzando Toe Piston(s)Stop Layout: Tilting/Rocking Tablets Above Top Manual
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination Action: Computerized/Digital
Control System: Unknown or N/A
Something missing or not quite correct?Add ConsoleorSuggest an Edit
DETAILS
Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location
Database Manager on November 23rd, 2018:
Updated by John Spencer, Principal Organist, All Saints', who maintains the organ.
Updated by John Spencer, Principal Organist, All Saints', who maintains the organ.
Database Manager on November 28th, 2006:
This entry represents tonal additions to an existing instrument. Identified through on-line information from James R. Stettner. -- Additions and extensions added to existing 1972 Balcom and Vaughan instrument.
Related Instrument Entries: Balcom and Vaughan Pipe Organs, Inc. (Opus 792, 1972)
