M. P. Möller
Opus 5614, 1929

Scottish Rite Cathedral [Coudersport Consistory]

Main Auditorium

111 East 2nd Street
Coudersport, PA, US

23 Ranks - 1,597 Pipes
Instrument ID: 31902 ● Builder ID: 3912 ● Location ID: 28238
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLIST
ADDITIONAL INFORMATION

Something not quite correct?Suggest an Edit

Plenum Organ Company

🤝 Instrument entries in Pennsylvania sponsored by:

We are grateful for the generous support of our sponsors, who make it possible for us to continue our mission of preserving and promoting the rich history of pipe organs across the globe.

IMAGES

Category:
Only show images in a specific category ☝️

Something missing or not quite correct?Add ImageorSuggest an Edit

STOPLISTS

Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
  • Position: In Side Chambers at the Front of the Room. No Visible Pipes
  • Chest Action: Electro Pneumatic (Pitman)
  • Stop Action: Pneumatic (Electro Pneumatic)
  • Notes: Enclosed with Choir, RH side of room.
  • Notes: 73 note duplex from Choir
  • Notes: 61 notes from Choir 8' English Open Diapason
  • Notes: 61 notes from Choir 8' Flute Harmonic
  • Notes: Great Tremolo and Choir Tremolo control the single tremolo unit for the Great/Choir chamber.
  • Notes: Deagan Electric Action with volume controller. 21 tubes.
  • 16' Great to Great
  • Great Unison Off
  • Notes: On/Off pistons atop right keycheek.
  • 4' Great to Great
  • 16' Swell to Great
  • 8' Swell to Great
  • 4' Swell to Great
  • 16' Choir to Great
  • 8' Choir to Great
  • 4' Choir to Great
8'61
8'73
8'73
8'73
8' CH
4' CH
4' CH
8'73
8'61
  • Position: In Side Chambers at the Front of the Room. No Visible Pipes
  • Chest Action: Electro Pneumatic (Pitman)
  • Stop Action: Pneumatic (Electro Pneumatic)
  • Notes: Enclosed with Great, RH side of room.
  • Notes: Also Great 4' Octave
  • Notes: 73 note duplex from Great
  • Notes: 73 note duplex from Great
  • Notes: Also 61 notes for Great 4' Flute Harmonic
  • Notes: Also draws 8' Dulciana
  • Notes: 61 notes from Great 8' Melodia
  • Notes: Great Tremolo and Choir Tremolo control the single tremolo unit for the Great/Choir chamber
  • 16' Choir to Choir
  • Choir Unison Off
  • Notes: On/Off pistons atop right keycheek.
  • 4' Choir to Choir
  • 16' Swell to Choir
  • 8' Swell to Choir
  • 4' Swell to Choir
8'73
8' GT
8' GT
8'73
8'73
8'61
4' GT
8'61
8'73
  • Position: In Side Chambers at the Front of the Room. No Visible Pipes
  • Chest Action: Electro Pneumatic (Details Unknown)
  • Stop Action: Pneumatic (Electro Pneumatic)
  • Notes: Chamber LH side of room
  • Notes: From 97 pipe unit flute. 73 notes, 12 pipes + 61 notes from 8' Gedeckt
  • Notes: From 97 pipe unit flute. 73 notes.
  • Notes: 73 notes
  • Notes: From 97 pipe unit flute. 73 notes, 61 notes from 8' Gedeckt and 12 pipes.
  • Notes: ext. 8' Salicional.
  • Notes: From 97 pipe unit flute. 61 notes, 54 pipes from 4' Orch. Flute plus 7 pipes
  • Notes: From 97 pipe unit flute. 61 notes, 56 notes from 2 2/3' Flute Twelfth plus 5 pipes.
  • Notes: Moller "Vox in a Box". Doors to box are open. Also turns on Swell Tremolo.
  • Notes: 49 notes Tenor "C" to c6.
  • Notes: Based on different style tab lettering and missing felt above the Glockenspiel and Xylophone tabs, I suspect these two stops were additions at some point. Non-functional at the time of my visit.
  • Notes: Based on different style tab lettering and missing felt above the Glockenspiel and Xylophone tabs, I suspect these two stops were additions at some point. Non-functional at the time of my visit.
  • 16' Swell to Swell
  • Swell Unison Off
  • Notes: On/Off pistons atop right keycheek.
  • 4' Swell to Swell
  • 16' Choir to Swell
  • 8' Choir to Swell
  • 4' Choir to Swell
16'12
8'73
8'73
8'61
8'73
8'61
8'61
4'12
4'12
2 2⁄3'7
2'5
8'73
8'73
8'73
  • Position: In Side Chambers at the Front of the Room. No Visible Pipes
  • Chest Action: Electro Pneumatic (Unit)
  • Stop Action: Pneumatic (Electro Pneumatic)
  • Notes: Pedal divided between Great/Choir chamber and Swell chamber.
  • Notes: 1 - 12, 16' Open Diapason 10 2/3' Bourdon, 13 - 32, 16' Open Diapason.
  • Notes: Enclosed in Swell chamber.
  • Notes: Enclosed in Great/Choir chamber
  • Notes: From Swell 97 pipe unit flute. 32 notes from Swell 16' Bourdon.
  • Notes: 32 notes, 20 from 16' Open Diapason, plus 12 pipes. Enclosed in Swell chamber.
  • Notes: 32 notes, 20 notes from 16' Bourdon plus 12 pipes. Enclosed in Great/Choir chamber.
  • Notes: 32 notes from Great/Choir Viole D'Gamba.
  • Notes: 32 notes, 12 pipes + 20 notes from Great 8' Trumpet.
  • 8' Swell to Pedal
  • 4' Swell to Pedal
  • 8' Great to Pedal
  • 4' Great to Pedal
  • 8' Choir to Pedal
32'
16'32
16'32
16' SW
8'12
8'12
8' GT
16'12 GT

FINGER PISTONS: Full Organ: 1-3, Swell 1-5, Great 1-5, Choir 1-5, Pedal 1-5; TOE LEVERS: Gr. to Ped. Reversible, Sforzando (rev); PEDAL MOVEMENTS: Great-Choir Expression (bal.), Swell Expression (bal.), Crescendo (bal.).

Open In New Tab

Something missing or not quite correct?Add StoplistorSuggest an Edit

CONSOLES

Selected Item:
View additional console entries if they exist ☝️
Builder: Unknown
Position: Unknown
Design: Unknown
Pedalboard Type: Unknown
Features:
3 Manuals 71 Registers
Stop Layout: Unknown
Expression Type: Unknown
Combination Action: Unknown
Control System: Unknown or N/A

Something missing or not quite correct?Add ConsoleorSuggest an Edit

DETAILS

Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location

Database Manager on December 4th, 2007:
Identified from factory documents and publications courtesy of Stephen Schnurr.
